The launch of KSCAN-X helps SCANTECH eliminate the limitations of previous common 3D scanner models. KSCAN-X was born with a single goal: "To become a wireless 3D scanner model to scan medium, large and super large sized parts with high accuracy".
Read moreMaximum flexibility with wireless scanner
KSCAN-X is a 3D scanner that operates completely wirelessly. Therefore, the device is allowed to scan without limits even in environments with limited power sources, at high altitudes or at long distances. Why KSCAN-X can perform these difficult tasks is thanks to the following features:
✔️Powerful integrated processor, easily handles large data sets.
✔️Dual battery system allows the machine to operate continuously, without the need for a cable connected to a power source.
✔️Dual-WNIC design technology allows high-speed data transmission but still stable.
Expanded Scanning Area & Depth of Field
The KSCAN-X's super-large scanning area of up to 2.6m × 1.8m and impressive depth of field from 0.3m to 2.5m make it the ideal solution for scanning objects of various sizes with high efficiency and accuracy.
The K-SCAN X 3D scanner scans super-large parts
Outstanding speed and accuracy
Equipped with four-directional green laser technology and a high-frame rate processing chip, this product ensures fast and seamless scanning even in harsh environments.
Key features include:
🔺4 × 21 four-directional green laser lines for high-speed large-area scanning.
🔺6,450,000 measurements per second for fast data collection.
🔺Scan speeds up to 180 FPS, allowing for smoother and more efficient scanning with fewer markers.
Various applications for multiple industries
The KSCAN-X can adapt to a variety of scanning needs with dedicated scanning modes:
👉🏻For super-large parts | High performance: Scan entire large surfaces in a single pass, leveraging adaptive photogrammetry to achieve superior accuracy at long distances. The KSCAN-X achieves exceptional accuracy of up to 0.075 mm, with volumetric accuracy of 0.075 mm + 0.010 mm/m.
👉🏻Medium to large-sized parts | Capture Fine Details: Provides 0.030 mm accuracy to ensure precise quality inspection, even for complex curves and the smallest details.
👉🏻Deep Hole Measurement | No Blind Spots: With a dedicated green laser line, the KSCAN-X excels at scanning hard-to-reach areas such as tube interiors and gear teeth.
Designed for Comfort and Efficiency:
The KSCAN-X incorporates an ergonomic design, ensuring seamless operation without fatigue:
✔️The intuitive frame with a perfect structure highlights key components such as the camera lens and laser system, allowing for seamless operation.
✔️Designed for comfort and efficiency, ensuring a firm grip and fatigue-free use, even during long scanning sessions.
✔️Designed with both ergonomics and aesthetics in mind, the KSCAN-X combines sharp, dynamic lines with a balanced, intuitive layout.
Integrated with next-generation measurement software.
Powered by the next-generation DefinSight platform, the KSCAN-X is built for industrial 3D scanning and inspection, offering an intuitive interface, broad compatibility, and high-speed data processing for an enhanced measurement experience.
👉🏻Easy to use: Smart, streamlined workflows that are easy to operate.
👉🏻For everyone: Designed for beginners and experts alike.
👉🏻Seamless scanning: Get up and running in no time with real-time data capture and packaging.
👉🏻High-resolution detail: Supports real-time mesh visualization for faster data collection and better data quality.
Revolutionizing wireless 3D scanning
With its combination of wireless operation, high-speed performance, and extreme accuracy, the KSCAN-X is set to transform large-area 3D scanning for industrial applications. Whether used in manufacturing, quality control, or complex engineering projects, the KSCAN-X delivers superior efficiency, accuracy, and ease of use.
